◇ Nominal Voltage : 3.6V

◇ Open circuit voltage : 3.67V

◇ Nominal Capacity : 77Ah (7700mAh)

◇ Pulse Capability : Typically up to 300 mA (0.1 second pulses)

◇ Maximum Recommended Continuous Current : 150mA

◇ Operating Temperature : −60 ~ 85°C


◇ Storage temperature : +30 ℃ max


◇ Diameter (max):  26.0 mm

◇ Height (max) :  49.1 mm

◇ Weight : 48g

*UL, IEC 60086-4, IEC 60079-11

                 < ↑ 마이너스(-) 극 >
