■ Rechargeable Lithium Ion Battery (리튬이온 충전배터리)
ㅡ 엘지 INR18650-MH1(3.7V 3200mAh)에 보호회로(PCM) 장착으로
길이가 약 5mm가 길어졌습니다.
◇ Nominal Voltage : 3.67V
◇ Nominal Capacity : 3200mAh
◇ Standard Charge : 4.2V, 0.5C (1550mA), End Current(Cut off) 50mA
◇ Max. Charge Current : 2A (because of the PCM specification)
◇ Standard Discharge : 0.2C (620mA), End Voltage(Cut off) 2.5V
◇ Max. Discharge Current : 2A (because of the PCM specification)
◇ Weight : 50g (about)
◇ Size : (4/3FA) 19 x 70mm (about)
◇ Operating Temperature : (Charge) 0 ~ 45℃, (Discharge) -20 ~ 60℃
(Storage) -20 ~ 20℃
|
